PrimitiveAlignment mechanics is broken when using canvas design size


TMTH
 Share

Recommended Posts

Here is PG. http://babylonjs-playground.com/#QTNKM#1

When using designSize on canvas alignment properties are unusable.

There are two different use cases:

1. I manually position primitive on some point. I expect it's position to be uniformly scaled from design size to real rendering size. That one is working.

2. I do not position primitive, but I set primitive alignment. Let it be marginHAlignment = BABYLON.PrimitiveAlignment.AlignRight. In that case I expect this primitive to be stuck on the right side of the rendered canvas. That case is not working.

So, building real UI  I have a problem. I can build UI panels using absolute positioning, and it will be OK, but how can I position those panels? Suppose I want one panel to be on left side of the canvas, and one on the right side - not so complex high level layout. Left one will be positioned fine, but with positioning right one I will have a problem. Big one.

@Nockawa, is there any work around for this?



Link to comment
Share on other sites

  • 2 weeks later...

Maybe this hasn't made it into the preview or the PG, or possibly I am using designSize wrong. But are these working right @Nockawa

http://babylonjs-playground.com/#2GDFI4 using position

http://babylonjs-playground.com/#2GDFI4#1 using marginalignment

Also I put a backgroundFill in, as I thought the idea of designSize was to grow/scale to fit the canvas.

Sorry if I should have created another thread, but this seemed on topic.



Link to comment
Share on other sites

@unintellisense well, yes, I had to rollback part of the code that were making this working (because unfortunately this code broke the scale propagation through primitive tree), as I said in other thread, that's the last thing I have to dev/check: alignment working correctly in all cases. I'm going to start that today, be a little more patient.

I hate that because C2D has been unstable lately, trying to make all features people asked working at the same time was quite a challenge...But the worst is definitely behind...

Link to comment
Share on other sites

You can find it here: https://github.com/nockawa/Babylon.js/tree/master/dist/preview release/canvas2D

But I'm about to make a big release with many changes/fix (good ones), I have one little thing to fix then I commit. So wait few hours or take immediately the actual file.

Make sure to watch this thread (http://www.html5gamedevs.com/topic/22552-canvas2d-main-post/), I post a message for every update of C2D



Link to comment
